- Gripping System - 250x150 mm suction pad - Air drawn 25.43 SCFM
ref. : CSGS4X15X35 -
- characteristics
-
Tensile force (Ft) 78.68Lbf dimension (D) 250x150mm Vacuum Flow (aa) 25.2SCFM Maximum vacuum (mv%) 75%
- Dimensions
-
3D Model
To generate the 3D file in the required format, we use the TRACEPARTS platform. To download the file, please use your TRACEPARTS username and password.
