- Intelligent Vacuum Pumps
Vacuum pumps are used in a wide variety of automated systems, primarily to generate and control vacuum in suction cups to ensure the gripping of objects. They must be easily integrated into a process and communicate the information necessary to ensure proper production.
To meet the expectations of manufacturers and the demands of automated applications, COVAL offers a complete range of vacuum pumps to meet different needs: vacuum levels, suction rates, control types, communication technologies, and energy savings.
-
- Controlled Micro Vacuum Pumps, MPXE Series
-
. Dia. 0.7; 1.0 mm nozzle
. Max. vacuum: 85%
. Suction flow up to 0.92 SCFM.
. Vacuum control: NC, NO
. Analog output.
. Standalone or bankable
more information
- Controlled Communicating Micro Vacuum Pumps, MPXS Series
-
. Dia. 0.7; 1 mm nozzle
. Max. vacuum: 85%
. Suction flow up to 0.92 SCFM.
. Vacuum control: NC, NO
. SIO/ IO-Link
. Vacuum regulator (ASC)
. Standalone or bankable
more information
- Integrated Mini-vacuum Pumps with ASR (Air Saving Regulator), LEM series
-
. Nozzle Ø : 1 ; 1.2 ; 1.4 mm
. 2 vacuum levels : 60% et 85%
. Suction flow rate : up to 3.25 SCFM
. Integrated pressure regulator (ASR)
. M8 connections
more information
- "Compact, High Flow Vacuum Pump with ""ASR"" (Air Saving Regulator) LEM+ series"
-
. Nozzle Ø : 2 ; 2.5 mm
. 2 vacuum levels : 60% et 85%
. Suction flow rate : up to 9.71 SCFM
. Integrated pressure regulator (ASR)
. M12 connections
more information
- "Integrated Mini-vacuum Pumps with ""ASC"" (Air Saving Control), LEMAX series"
-
. Nozzle Ø : 1 ; 1.2 ; 1.4 mm
. Vacuum level : 85%
. Suction flow rate : up to 2.47 SCFM
. Integrated pressure regulator (ASR)
. Integrated vacuum regulator (ASC)
. M8 connections
more information
- Mini Vacuum Pumps with Communication IO-Link, LEMAX IO
-
. Nozzle Ø : 1 ; 1.2 ; 1.4 mm
. Vacuum level : 85%
. Suction flow rate : up to 70 Nl/min
. Integrated pressure regulator (ASR)
. Integrated vacuum regulator (ASC)
. IO-Link
more information
- Compact, High Flow Vacuum Pump with "ASC" (Air Saving Control) LEMAX+ series
-
. Nozzle Ø : 2 ; 2.5 mm
.Vacuum levels : 85%
. Suction flox rate : up to 7.06 SCFM
. Integrated pressure regulator (ASR)
. Integrated vacuum regulator (ASC)
. M12 connections
more information
- Mini-vacuum Pump Communicating via Industrial Fieldbus, LEMCOM series
-
. Nozzle Ø : 1 ; 1.2 ; 1.4 mm
. Vacuum levels : 60% et 85%
. Suction flow rate : up to 3.25 SCFM
. Field bus : PROFINET - EtherNet/IP
. Integrated technology : ASR - ASC
. M8 connections
more information
- Heavy Duty Communicating Vacuum Pumps, GVMAXHD Series
-
. Dia. 2.5; 3 mm nozzle
. Max. vacuum: 85%
. Suction flow up to 8.05 SCFM
. Vacuum control: NC, NO or pulse-triggered bistable control
. IO-Link and NFC
. Vacuum regulator (ASC)
. Standalone or in island assemblies
more information
- Heavy Duty Multi-Stage Vacuum Pumps, CMS HD Series
-
. Flow rate up to 56.50 SCFM
. 80% vacuum pressure
. Multi-stage technology
. With or without vacuum and blowoff control
. Vacuum control: NC or NO
. M12 connection
. 3 exhaust configurations
more information
- Multi-stage mini vacuum pumps, CMS M Series
-
. Flow rate up to 550 Nl/min
. 80% vacuum
. Multi-stage technology
. With or without vacuum and blowoff control
. Vacuum control: NC or NO
. M12 connection
. 2 exhaust configurations
more information
- Self-regulating Vacuum Pumps (electric vacuum and blow-off control), GVMAXV2-2 series
-
. Nozzle Ø : 2.5 mm
. Maximum vacuum : 90%
. Suction power : up to 7.06 SCFM
. Vacuum regulation function
. M12 connection
more information
- Self-regulating Vacuum Pumps (electric vacuum and blow-off control), GVMAX E1 series
-
. Nozzle Ø : 2.5 mm
. 3 levels of vacuum : 50% - 75% - 90%
. Suction flow rate : up to 12.71 SCFM
. Vacuum regulation function
more information
- Self-regulating Vacuum Pumps (pneumatic vacuum and blow-off control), GVMAX P1 series
-
. Nozzle Ø : 2.5 mm
. 3 levels of vacuum : 50% - 75% - 90%
. Suction flow rate : up to 12.71 SCFM
. Vacuum regulation function
more information
- Self-regulating vacuum pumps (pneumatic vacuum and blow-off control), GVMAXNK14P2 series
-
. Nozzle Ø : 2.5 mm
. Maximum vacuum : 85%
. Suction flow rate : up to 7.06 SCFM
. Integrated vacuum regulator
. 2 pneumatic vacuum switch
more information
